The Mitsubishi PS21265-P is a high-performance Intelligent Power Module (IPM) from Mitsubishi Electric's DIP-IPM series, offering a highly integrated solution for 3-phase AC motor drive and inverter applications. Rated at 20A and 600V, this module incorporates six IGBTs along with optimized gate drive circuitry and comprehensive protection functions — all within a compact, low-profile dual-inline package. The built-in intelligence of the PS21265-P significantly reduces system complexity, shrinks board space requirements, and accelerates design cycles for power electronics engineers.

The PS21265-P is well-suited for a broad range of industrial and consumer applications including variable frequency drives (VFDs), general-purpose inverters, HVAC compressor drives, pump and fan controllers, servo drives, and solar micro-inverters. Its integrated bootstrap power supply capability and isolated control inputs make it an excellent choice for cost-sensitive, space-constrained drive designs that still demand high reliability and robust protection.

Quick Reference: PS21265-P

Key Features:

• 20A, 600V 3-phase IGBT inverter bridge with integrated gate drivers
• Built-in overcurrent, short-circuit, undervoltage lockout (UVLO), and overtemperature protection
• Compact DIP-IPM package simplifies PCB layout and reduces overall system footprint
• Isolated control signal inputs compatible with standard microcontroller and DSP drive signals
• Bootstrap power supply circuitry for upper arm gate drive eliminates need for isolated supplies
• Low switching losses and optimized IGBT characteristics for high-efficiency motor drive performance

Sourcing Mitsubishi IPMs such as the PS21265-P can be challenging through standard distribution channels, particularly for production runs, service replacements, or legacy equipment repairs. ATI Accurate Technology specializes in exactly these scenarios — maintaining inventory of hard-to-find, long-lead-time, and obsolete power semiconductors to ensure our customers can keep their production lines running and their equipment in service without extended delays.

ATI Accurate Technology is your trusted source for the PS21265-P and the full range of Mitsubishi Intelligent Power Modules. Located in Palmetto, Florida, ATI ships same-day on all orders received before 5PM EST. Contact our power semiconductor specialists today at 239-734-7566 or email sales@igbts.us for pricing, availability, and technical support.
