The Mitsubishi PM75RLB120 is a 75A, 1200V Intelligent Power Module (IPM) built around Mitsubishi's proven IGBT technology with fully integrated gate drive and protection functions. As an IPM, it combines the switching stage with on-board control, overcurrent protection, short-circuit protection, undervoltage lockout, and fault output signaling — all in a single compact package. This level of integration accelerates design cycles and improves system reliability in high-voltage power conversion applications where discrete component count and thermal management are primary engineering concerns.

The PM75RLB120 is well-suited for three-phase AC motor drives, servo amplifiers, UPS systems, industrial inverters, and general-purpose frequency converters operating from 400V to 690V AC bus architectures. Its robust protection suite makes it a preferred choice for OEM equipment builders and field engineers maintaining legacy drive systems in manufacturing, HVAC, pump and fan controls, and material handling equipment. The integrated fault output simplifies system-level fault diagnostics and reduces time-to-repair in production environments where uptime is critical.

Quick Reference: PM75RLB120

Key Features of the PM75RLB120:

• 75A continuous collector current with 1200V CE voltage rating for 600V–690V AC bus applications
• Integrated gate drive circuitry eliminates the need for external IGBT driver design and layout
• Built-in overcurrent, short-circuit, and undervoltage lockout (UVLO) protection with isolated fault output signal
• Low thermal resistance junction-to-case supports high-power-density mounting on standard heatsink assemblies
• Optimized switching characteristics balance conduction loss and switching loss across the full load range
• Industry-standard module footprint for direct replacement in existing drive platforms and legacy inverter designs

With a current factory lead time of 99 weeks, the PM75RLB120 presents a serious procurement challenge for both new equipment builds and unplanned maintenance situations. Extended lead times at this level effectively mean new production is not a viable option for urgent needs, scheduled outages, or end-of-line drive repairs. Procurement teams managing spares inventories for Mitsubishi-based drive systems should treat available stock as a finite resource. ATI specializes in exactly this scenario — sourcing and stocking hard-to-find, long-lead-time, and legacy IPM modules so your operation is not held hostage to a 2-year manufacturing queue.

ATI Accurate Technology is based in Palmetto, Florida and stocks the PM75RLB120 as new OEM product ready for same-day shipment on orders placed before 5PM EST. Whether you need a single replacement module or are building a multi-site spare parts program, ATI offers responsive service and volume pricing. Contact our power semiconductor specialists directly at 239-734-7566 or sales@igbts.us to confirm availability, request a quote, or discuss blanket order options.
