The Mitsubishi PM100CLA060 is a 100A, 600V Intelligent Power Module (IPM) combining high-speed IGBT chips with integrated gate drive circuitry, bootstrap power supply, and onboard protection functions including over-current, short-circuit, under-voltage lockout, and over-temperature shutdown. The IPM architecture offloads protection logic from the external DSP or MCU, reducing system component count and design complexity. The PM100CLA060 targets three-phase inverter topologies and is packaged in Mitsubishi's industry-standard DIP-IPM footprint, simplifying drop-in replacement across compatible drive platforms.

The PM100CLA060 sees widespread deployment in variable frequency drives (VFDs), servo amplifiers, uninterruptible power supplies (UPS), HVAC compressor drives, pump and fan controls, and general-purpose industrial inverters rated in the 5–15 kW range. Its integrated protection suite reduces mean time to failure in harsh factory environments and minimizes design overhead for OEM equipment builders. The module is equally suited to field replacement scenarios where maintainability, thermal reliability, and sourcing continuity are primary concerns for plant engineers and MRO procurement teams.

Quick Reference: PM100CLA060

Key Features of the PM100CLA060:

• 100A / 600V three-phase IGBT inverter bridge in a compact DIP-IPM package
• Integrated gate drive with bootstrap power supply eliminates external gate resistor networks
• Hardware-level over-current and short-circuit protection with fault output signal to system controller
• Under-voltage lockout (UVLO) on each phase arm prevents mis-firing during power sequencing
• On-chip NTC thermistor output enables real-time module temperature monitoring by the host controller
• Industry-standard pinout provides direct interchangeability with compatible Mitsubishi CLA-series IPM footprints

With a current factory lead time of 44 weeks on new production, procurement teams supporting active production lines or critical MRO spares programs face significant exposure if the PM100CLA060 is not already in the supply chain. Extended lead times on Mitsubishi IPMs have become a recurring challenge across industrial drive markets, and obsolescence risk increases as legacy equipment ages. Sourcing from a stocking distributor eliminates that exposure entirely, allowing maintenance operations to pull parts the same day a drive failure occurs rather than waiting nearly a year for factory fulfillment.

ATI Accurate Technology is a power semiconductor distributor located in Palmetto, Florida, stocking IGBTs, IPMs, thyristors, diodes, and rectifier modules including hard-to-find and long-lead-time parts like the PM100CLA060. Orders placed before 5PM EST ship same day. Volume pricing is available for OEM builds, MRO blanket orders, and production spares kits. Contact ATI at 239-734-7566 or sales@igbts.us to confirm availability and receive a quote.
