The Sanrex DF50BA80 is a single-phase bridge rectifier module delivering robust AC-to-DC conversion in a compact, thermally efficient package. Rated at 50 amperes continuous current and 800 volts peak repetitive reverse voltage, this diode module is engineered for reliable performance in demanding industrial and commercial power electronics environments. Sanrex's proven module technology ensures low forward voltage drop, excellent thermal conductivity through the isolated baseplate, and long operational life under continuous load conditions.

The DF50BA80 is well suited for a wide range of power conversion applications including variable speed motor drives, industrial power supplies, welding equipment, battery charging systems, uninterruptible power supplies (UPS), and general-purpose rectification circuits. Its bridge configuration eliminates the need for discrete component assembly, reducing BOM complexity and improving system reliability in both OEM designs and field replacement scenarios.

Quick Reference: DF50BA80

Key Features:

• 50A continuous forward current rating for medium-power rectification applications
• 800V peak repetitive reverse voltage (VRRM) for reliable operation on standard industrial AC lines
• Single-phase full-wave bridge rectifier topology in a single integrated module
• Isolated copper baseplate for direct heatsink mounting and improved thermal management
• Compact module footprint reduces PCB space and simplifies system integration
• Manufactured by Sanrex, a trusted Japanese power semiconductor brand known for quality and longevity

Sourcing the DF50BA80 can be a challenge through standard distribution channels, particularly for maintenance, repair, and retrofit applications where legacy Sanrex modules are specified. ATI Accurate Technology maintains inventory of hard-to-find and long-lead-time Sanrex power semiconductor modules, including the DF50BA80, ensuring that engineers and procurement teams can secure the exact parts they need without costly project delays.

ATI Accurate Technology is your trusted source for the Sanrex DF50BA80 and hundreds of other power semiconductor modules. Located in Palmetto, Florida, ATI specializes in IGBTs, diodes, thyristors, and rectifier modules from leading global manufacturers. Orders placed before 5PM EST ship same day. Contact our team today at 239-734-7566 or email sales@igbts.us for pricing, availability, and technical support.
