The Mitsubishi CM800DXLE-24A is a high-current IGBT module engineered for performance-critical power electronics applications. Built on Mitsubishi's proven DX-series platform, this dual IGBT configuration delivers 800A collector current capability with a 1200V blocking voltage, making it well-suited for high-power inverter stages where switching efficiency, thermal stability, and rugged gate-drive compatibility are non-negotiable. The module's low V_CE(sat) characteristic reduces conduction losses, while its co-packaged freewheeling diodes simplify system design and reduce external component count in bridge topologies.

The CM800DXLE-24A sees widespread use in medium-voltage industrial motor drives, regenerative AC drive systems, UPS inverter stages, induction heating equipment, and traction power converters. Its form factor and current rating make it a natural fit for retrofit and redesign work in legacy drive platforms as well as new designs where high pulse current handling and reliable short-circuit withstand capability are required. Engineers in steel, mining, oil and gas, marine propulsion, and renewable energy sectors regularly specify this module for converter and chopper stages operating under continuous heavy load.

Quick Reference: CM800DXLE-24A

Key Features of the CM800DXLE-24A:

• 800A continuous collector current with 1200V collector-emitter voltage rating for high-power inverter and converter stages
• Low V_CE(sat) optimized to minimize on-state conduction losses at full load, reducing thermal stress on the module and heatsink assembly
• Integrated co-packaged freewheeling diodes with fast reverse recovery characteristics, reducing switching losses in PWM drive applications
• High short-circuit withstand capability with defined 10µs safe operating area, critical for industrial drive fault protection schemes
• Industry-standard DX-series module footprint ensures dimensional compatibility with existing heatsink, busbar, and gate driver designs
• Isolated copper baseplate construction for efficient thermal transfer and electrical isolation from the heatsink in densely packaged power assemblies

With a factory lead time of 36 weeks for new production runs, procurement teams relying solely on the OEM supply chain risk costly downtime and project delays. The CM800DXLE-24A is a high-demand module frequently needed for emergency drive repairs, MRO inventory replenishment, and production line continuity. ATI Accurate Technology maintains stock of hard-to-find and long-lead-time IGBT modules precisely to bridge this gap. Whether you need a single unit to get a line back online today or a scheduled volume order, ATI provides verified new OEM parts with full traceability.

ATI Accurate Technology is located in Palmetto, Florida and ships same-day on orders received before 5PM EST. We specialize in IGBTs, thyristors, diodes, and rectifier modules — including obsolete and allocated parts other distributors can't source. Volume pricing is available for OEM and MRO customers. Contact our team directly at 239-734-7566 or sales@igbts.us for quotes, technical questions, or expedited order processing.
