The Mitsubishi CM200DY-12E is a dual IGBT module rated at 200 amperes and 1200 volts, packaged in the industry-standard DY configuration housing two discrete IGBT switches with integrated freewheeling diodes. This module is built on Mitsubishi's mature IGBTMOD process, delivering low collector-emitter saturation voltage (V_CE(sat)), tight parameter matching between the two switches, and a thermally optimized isolated copper baseplate. The CM200DY-12E is engineered for reliable, long-cycle operation in demanding power conversion environments where thermal performance and switching consistency are critical.

The CM200DY-12E sees widespread deployment across industrial and heavy-equipment sectors. Primary applications include three-phase AC variable frequency drives (VFDs), industrial servo amplifiers, UPS inverter stages, induction heating systems, and railway auxiliary converters. Its 1200V blocking capability provides adequate voltage margin for 690VAC bus architectures after DC link rectification. The module is also found in welding inverters, elevator drive systems, and medium-power renewable energy inverters where a compact, dual-switch topology simplifies gate driver layout and reduces overall system component count.

Quick Reference: CM200DY-12E

Key Features of the CM200DY-12E:

• 1200V V_CES blocking voltage with 200A continuous collector current rating, suitable for 690VAC industrial drive applications
• Dual (2-in-1) IGBT topology with co-packaged fast-recovery freewheeling diodes for each switch, reducing external component requirements
• Low V_CE(sat) characteristic minimizes conduction losses and reduces heatsink thermal requirements at full load
• Isolated copper baseplate construction enables direct heatsink mounting without additional isolation pads in most configurations
• Industry-standard DY footprint and pin-out ensures form-fit-function compatibility with existing PCB and busbar designs
• Designed for gate drive voltages of +15V / -15V with specified short-circuit withstand time for robust fault tolerance in drive systems

With a factory lead time of 36 weeks for new production, the CM200DY-12E presents a serious procurement challenge for maintenance teams managing unplanned downtime or engineers commissioning new equipment on tight schedules. Distributor stock is the practical solution. ATI Accurate Technology maintains inventory of the CM200DY-12E specifically to bridge this gap — whether you need a single module for an emergency repair or a buffer stock quantity to protect a fleet of drives. All units are new, genuine OEM product, not reconditioned or remarked.

ATI Accurate Technology is a power semiconductor specialist located in Palmetto, Florida, stocking IGBTs, thyristors, diodes, and rectifier modules including obsolete and long-lead-time parts. Orders placed before 5PM EST ship same day. Contact our team for volume pricing, technical questions, or cross-reference assistance: 239-734-7566 or sales@igbts.us. We serve maintenance engineers and procurement professionals who need the right part fast.
