The Infineon BSM15GD120DN12 is a 1200V, 15A dual IGBT module housed in the compact ECONOPACK DN12 package. Designed around Infineon's proven trench-gate IGBT technology, this module integrates fast-recovery freewheeling diodes and delivers low collector-emitter saturation voltage (V_CE(sat)), making it well suited for high-frequency switching converters where switching losses and thermal performance are critical design constraints. The DN12 package simplifies PCB integration with a standardized footprint and isolated baseplate, supporting straightforward thermal management in space-constrained assemblies.

The BSM15GD120DN12 sees broad deployment across industrial and commercial power electronics platforms. Typical applications include three-phase AC motor drives, solar inverters, UPS systems, servo amplifiers, induction heating equipment, and switched-mode power supplies operating from a DC bus. Its 1200V blocking voltage provides adequate margin for 690V AC mains applications, while the 15A current rating targets fractional to low-kilowatt drive systems. OEM equipment manufacturers and MRO teams servicing legacy variable-frequency drives frequently specify this module as a direct replacement or upgrade component.

Quick Reference: BSM15GD120DN12

Key Features of the BSM15GD120DN12:

• 1200V collector-emitter blocking voltage (V_CES) with 15A continuous collector current rating for 690V-class drive applications
• Low V_CE(sat) trench-gate IGBT technology minimizes conduction losses and reduces heat sink requirements at typical operating currents
• Integrated co-pack freewheeling diodes with optimized reverse recovery characteristics for reduced switching transients and EMI
• Isolated copper baseplate in the ECONOPACK DN12 package ensures electrical isolation from heatsink while maintaining low thermal resistance (R_th(j-c))
• Suitable for switching frequencies up to several kilohertz, balancing switching loss and conduction loss in PWM inverter topologies
• Compliant with RoHS requirements; compatible with standard power module gate driver ICs and bootstrap driver circuits

With factory lead times for the BSM15GD120DN12 currently stretching to 99 weeks through standard distribution channels, procurement teams supporting production lines or maintaining critical drive systems cannot afford to rely on new factory orders alone. Whether you're managing a planned maintenance schedule, responding to an unplanned equipment failure, or building safety stock for an aging platform, sourcing from a stocking distributor that carries genuine new OEM inventory is the most reliable path to minimizing downtime. ATI Accurate Technology maintains verified inventory of hard-to-find and long-lead-time IGBT modules including the BSM15GD120DN12, enabling immediate fulfillment without the multi-year wait.

ATI Accurate Technology is headquartered in Palmetto, Florida and specializes in power semiconductors including IGBTs, thyristors, diodes, and rectifier modules. Orders placed before 5PM EST ship same day. Contact our team for volume pricing, cross-reference assistance, or emergency procurement support. Call 239-734-7566 or email sales@igbts.us—we're here to keep your equipment running.
